Dell Embedded Box PC5000 Service Manual

• 8 mm open wrench
• 10 mm open wrench
Screw list
The following table provides the list of screws used for securing dierent components
to the Embedded Box PC.
Component Secured to Screw type Quantity
Logo board Front chassis M3x5 3
Left chassis Front chassis M3x6 7
Right chassis Front chassis M3x6 7
System board Front chassis M3x5 9
Front chassis STDF(L8) HEX, M3x4 5
Front chassis STDF(L15) HEX, M3x4 1
CPU board System board STDF(L5) HEX, M2.5x4 3
System board M2.5x6 2
Heat sink CPU board M3x8 4
Left chassis M3x16 4
Right chassis M3x16 4
Riser card Riser card
bracket
M3x5 2
Riser card Right chassis M3x5 countersunk 2
WLAN card Carrier board M2x3 2
WWAN card Carrier board M2x3 2
PCI cover Top PCI plate M3x5 countersunk 1
PCI cover Top PCI plate M3x5 countersunk 1
PCI bracket Top PCI plate M3x5 countersunk 1
DC-in connector Top PCI plate M2.5x6 2
Intrusion switch Intrusion-
switch bracket
M2x10 1
13
