Dell Embedded Box PC5000 Service Manual

Replacing the solid-state drive in
to bracket
WARNING: Before working inside your Embedded Box PC, read the safety
information that shipped with your Embedded Box PC and follow the steps
in Before working inside your Embedded Box PC. After working inside your
Embedded Box PC, follow the steps in After working inside your Embedded
Box PC. For more safety best practices, see the Regulatory Compliance
home page at
www.dell.com/regulatory_compliance.
CAUTION: Solid-state drives are fragile. Exercise care when handling the
solid-state drive.
Procedure
1 Align the notch on the solid-state drive with the tab on the solid-state drive slot.
2 Slide the solid-state drive rmly into the slot and align the screw hole on the
solid-state drive with the screw hole on the solid-state drive bracket
3 Replace the screw that secures the solid-state drive to the solid-state drive
bracket.
Post-requisites
1 Replace the drives in to the hard-drive cage.
2 Follow step 2 to step 8 in “Replacing the back cover”.
