Dell Embedded Box PC5000 Service Manual

Replacing the intrusion switch
WARNING: Before working inside your Embedded Box PC, read the safety
information that shipped with your Embedded Box PC and follow the steps
in Before working inside your Embedded Box PC. After working inside your
Embedded Box PC, follow the steps in After working inside your Embedded
Box PC. For more safety best practices, see the Regulatory Compliance
home page at www.dell.com/regulatory_compliance.
Procedure
1 Replace the screw that secures the intrusion switch to the chassis.
2 Route the intrusion-switch cable through the routing guides on the chassis and
under the heat sink pipe.
3 Connect the intrusion-switch cable to the intrusion-switch connector on the
system board.
Post-requisites
1 Replace the PCI/PCIe card (if necessary).
2 Follow step 2 to step 8 in “Replacing the back cover”.
89
