Dell Embedded Box PC5000 Service Manual

Replacing the WLAN card
WARNING: Before working inside your Embedded Box PC, read the safety
information that shipped with your Embedded Box PC and follow the steps
in Before working inside your Embedded Box PC. After working inside your
Embedded Box PC, follow the steps in After working inside your Embedded
Box PC. For more safety best practices, see the Regulatory Compliance
home page at www.dell.com/regulatory_compliance.
Procedure
NOTE: To avoid damage to the WLAN card, do not place any cables under it.
1 Align the notch on the WLAN card with the tab on the mPCIE2 slot.
2 Insert the WLAN card at an angle into the mPCIE2 slot.
3 Insert the WLAN-card bracket into the WLAN card.
4 Align the screw holes on the WLAN-card bracket with the screw holes on the
system board.
5 Replace the screws that secure the WLAN-card bracket to the system board.
61
