Dell Embedded Box PC5000 Service Manual

Replacing the CANbus card
WARNING: Before working inside your Embedded Box PC, read the safety
information that shipped with your Embedded Box PC and follow the steps
in Before working inside your Embedded Box PC. After working inside your
Embedded Box PC, follow the steps in After working inside your Embedded
Box PC. For more safety best practices, see the Regulatory Compliance
home page at www.dell.com/regulatory_compliance.
Procedure
1 Align the notch on the CANbus card with the tab on the mPCIE1 slot.
2 Insert the CANbus card at an angle into the mPCIE1 slot.
3 Align the screw holes on the CANbus card with the screw holes on the system
board.
4 Replace the screws that secure the CANbus card to the system board.
