Dell Embedded Box PC5000 Service Manual

Replacing the serial ports
WARNING: Before working inside your Embedded Box PC, read the safety
information that shipped with your Embedded Box PC and follow the steps
in Before working inside your Embedded Box PC. After working inside your
Embedded Box PC, follow the steps in After working inside your Embedded
Box PC. For more safety best practices, see the Regulatory Compliance
home page at www.dell.com/regulatory_compliance.
Procedure
1 Connect the serial-port cable to the connector on the system board.
2 Insert the serial ports into the respective slots on the bottom cover.
NOTE: Match the port number with the number on the cable.
3 Replace the hexagonal screws that secure the serial ports to the bottom-cover.
Post-requisites
1 Replace the PCI/PCIe card (if necessary).
2 Follow step 2 to step 8 in “Replacing the back cover”.
