Dell Embedded Box PC5000 Service Manual

Replacing the CPU board
WARNING: Before working inside your Embedded Box PC, read the safety
information that shipped with your Embedded Box PC and follow the steps
in Before working inside your Embedded Box PC. After working inside your
Embedded Box PC, follow the steps in After working inside your Embedded
Box PC. For more safety best practices, see the Regulatory Compliance
home page at www.dell.com/regulatory_compliance.
Procedure
1 Place the CPU board on the CPU-board connector the system board.
2 Carefully, press down on the CPU board.
3 Align the screw holes on the CPU board with the screw holes on the system
board.
4 Replace the screws that secure the CPU board to the system board.
Post-requisites
1 Replace the heat sink.
2 Replace the memory module.
3 Replace the PCI/PCIe card (if necessary).
4 Follow step 2 to step 8 in “Replacing the back cover”.
