Dell Embedded Box PC5000 Service Manual

Replacing the WWAN card
WARNING: Before working inside your Embedded Box PC, read the safety
information that shipped with your Embedded Box PC and follow the steps
in Before working inside your Embedded Box PC. After working inside your
Embedded Box PC, follow the steps in After working inside your Embedded
Box PC. For more safety best practices, see the Regulatory Compliance
home page at www.dell.com/regulatory_compliance.
Procedure
NOTE: To avoid damage to the WWAN card, do not place any cables under
it.
1 Align the notch on the WWAN card with the tab on the mPCIE1 slot.
2 Insert the WWAN card at an angle into the mPCIE1 slot.
3 Align the screw holes on the WWAN card with the screw holes on the system
board.
4 Replace the screws that secure the WWAN card to the system board.
70
