Replacing the power connectors
WARNING: Before working inside your Embedded Box PC, read the safety
information that shipped with your Embedded Box PC and follow the steps
in Before working inside your Embedded Box PC. After working inside your
Embedded Box PC, follow the steps in After working inside your Embedded
Box PC. For more safety best practices, see the Regulatory Compliance
home page at www.dell.com/regulatory_compliance.
Procedure
1 Insert the power cables along with the barrel connector through the slot on the
chassis.
2 Replace the screws that secure the power connector to the chassis.
3 Route the power cable through the routing guide on the system board.
4 Connect the power cable to the system board.
5 Replace the screw that secures the grounding cable to the system board.
6 Insert the barrel connector through the chassis.
7 Replace the nut and washer that secure the barrel connector to the chassis.
Post-requisites
1 Replace the heat sink.
2 Replace the PCI/PCIe card (if necessary).
3 Follow step 2 to step 8 in “Replacing the back cover”.
108
