Table 30. Config12-1: R1D+R2A+R3A+R4A(FL)
Agile Description Supplier Category Card Priority
KIT,CRD,NVME,3.2,HHHL,PM
1725B
SAMSUNG PCIE SSD 12300
KIT,CRD,NVME,6.4,HHHL,PM
1725B
SAMSUNG PCIE SSD 12400
KIT,CRD,NVME,1.6,HHHL,PM
1735
SAMSUNG PCIE SSD 12500
KIT,CRD,NVME,1.6,HHHL,PM
1735,O
SAMSUNG PCIE SSD 12600
KIT,CRD,NVME,3.2,HHHL,PM
1735
SAMSUNG PCIE SSD 12700
KIT,CRD,NVME,3.2,HHHL,PM
1735,O
SAMSUNG PCIE SSD 12800
KIT,CRD,NVME,6.4,HHHL,PM
1735
SAMSUNG PCIE SSD 12900
KIT,CRD,NVME,6.4,HHHL,PM
1735,O
SAMSUNG PCIE SSD 13000
KIT,CRD,NVME,750GB,HHHL,
P4800X
INTEL PCIE SSD 13100
Removing the expansion card risers
Prerequisites
1. Follow the safety guidelines listed in the Safety instructions.
2. Follow the procedure listed in the Before working inside your system.
3. Disconnect any cables that are connected to the expansion card.
Steps
1. For Riser 1, loosen the captive screws on the riser.
a. Press the blue release tab and holding the edges lift the expansion card riser from the riser connector on the system
board.
NOTE: The numbers on the image do not depict the exact steps. The numbers are for representation of sequence.
118 Installing and removing system components
