Upgrade Kits
The table lists the available After Point Of Sale [APOS] kits.
Table 31. Upgrade kits
Kits Part number Related links to service instructions
Bezel JYPW8/MPW3H (LCD) See Installing the front bezel
Boss See Installing the M.2 SSD module
BOSS S2 See Installing the BOSS S2 controller card module
Embedded management (IDSDM) C2KCJ See IDSDM kit
GPU See GPU kit
Accelerator enablement kit See GPU kit
Hard drives See Installing the drive
Hard drives SSD See Installing the drive into the carrier
Memory See Installing a memory module
Network cards (Standard PCIe
adapter LP/FH)
See Installing the LOM card and rear I/O board
Network cards (OCP) See Installing the OCP card
PCIe SSD card See Installing an expansion card into the expansion card riser
Power cords
Power supplies See Installing a power supply unit
Quick sync C70VC (PE) / 8XK5Y
(OEM)
SD cards See Installing the MicroSD card
TPM JD9CH See Upgrading the Trusted Platform Module
Processor enablement thermal kits TVMK2/C82YT/8T3V2/
JWDV5/NP3NR
See Installing the processor
Internal USB 3.0 card C19XC See Internal USB card kit
Serial COM port daughter card 626YT See Installing the serial COM port
Topics:
• BOSS S2 kit
• GPU kit
• IDSDM kit
• Internal USB card kit
• Serial COM port kit
BOSS S2 kit
The BOSS S2 supports up to two M.2 SSDs.
5
Upgrade Kits 169
