Steps
1. Connect the battery cable to the connector on the system board.
2. Adhere the tape to secure the battery cable to the connector on the system board.
3. Place the base cover on top of the palm-rest and keyboard assembly.
4. Align the screw holes on the base cover to the screw holes on the palm-rest and keyboard assembly, and snap the base
cover latches into place.
5. Tighten the two captive screws to secure the base cover to the palm-rest and keyboard assembly.
6. Replace the six screws (M2x4) to secure the base cover to the palm-rest and keyboard assembly.
Next steps
1. Follow the procedure in After working inside your computer.
M.2 solid-state drive
Removing the M.2 2230 solid-state drive
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the base cover.
About this task
NOTE: This procedure applies only to computers shipped with a M.2 2230 solid-state drive installed.
NOTE: The M.2 solid-state drive installed on your computer depends on the configuration ordered. The M.2 slot supports
one of the following solid-state drives:
● M.2 2230 solid-state drive
A mounting bracket for the M.2 2230 solid-state drive is required. The mounting bracket is provided if the M.2 2230
solid-state is shipped with the computer.
If you are replacing the M.2 2230 solid-state drive with a new M.2 2230 solid-state drive, use the existing mounting
bracket to install the latter.
● M.2 2280 solid-state drive
If you are replacing the M.2 2280 solid-state drive (shipped with the computer) with an M.2 2230 solid-state drive, a
mounting bracket for the M.2 2230 solid-state drive is required. Contact Dell support to purchase the mounting bracket
for the M.2 2230 solid-state drive.
The following images indicate the location of the M.2 2230 solid-state drive and provide a visual representation of the removal
procedure.
Removing and installing Customer Replaceable Units (CRUs)
39
