Steps
1. Place the coin-cell battery on the slot on the palm-rest and keyboard assembly.
2. Connect the coin-cell battery cable to the connector on the I/O daughter-board.
Next steps
1. Install the I/O daughter-board cable.
2. Install the base cover.
3. Follow the procedure in After working inside your computer.
Power button
Removing the power button
CAUTION: The information in this section is intended for authorized service technicians only.
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the base cover.
3. Remove the I/O daughter-board cable.
4. Remove the I/O daughter-board.
About this task
The following image indicates the location of the power button and provides a visual representation of the removal procedure.
Removing and installing Field Replaceable Units (FRUs)
67
