Prerequisites
If you are replacing a component, remove the existing component before performing the installation process.
About this task
The following images indicate the location of the display bezel and provide a visual representation of the installation procedure.
Steps
1. Align and place the display bezel on the display assembly.
2. Gently snap the display bezel into place.
Next steps
1. Install the display assembly.
2. Install the WLAN card.
3. Install the 4G WWAN card or 5G WWAN card, as applicable.
4. Install the base cover.
5. Install the SIM card.
6. Follow the procedure in After working inside your computer.
Display panel
Removing the display panel
CAUTION: The information in this section is intended for authorized service technicians only.
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the SIM card.
3. Remove the base cover.
104
Removing and installing Field Replaceable Units (FRUs)
