Steps
1. Align and place the camera module into the slot on the display back cover.
2. Connect the camera module cable to the connector on the camera module.
3. Adhere the tape to secure the camera cable to the camera.
Next steps
1. Install the display panel.
2. Install the display bezel.
3. Install the display assembly.
4. Install the WLAN card.
5. Install the 4G WWAN card or 5G WWAN card, as applicable.
6. Install the base cover.
7. Install the SIM card.
8. Follow the procedure in After working inside your computer.
Display hinges
Removing the display hinges
CAUTION: The information in this section is intended for authorized service technicians only.
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the SIM card.
3. Remove the base cover.
4. Remove the 4G WWAN card or 5G WWAN card, as applicable.
5. Remove the WLAN card.
6. Remove the display assembly.
7. Remove the display bezel.
8. Remove the display panel.
About this task
The following images indicate the location of the display hinges and provide a visual representation of the removal procedure.
112
Removing and installing Field Replaceable Units (FRUs)
