Steps
1. Align and place the power button on the palm-rest assembly.
2. Replace the two (M2x2.5) screws to secure the power button to the palm-rest assembly.
Next steps
1. Install the system board.
2. Install the assembly-inner frame.
3. Install the heat sink (discrete GPU) or heat sink (integrated GPU), as applicable.
4. Install the M.2 2230 solid-state drive in Slot 2, if applicable.
5. Install the M.2 2230 or M.2 2280 solid-state drive in Slot 1, as applicable.
6. Install the memory modules.
7. Install the WLAN card.
8. Install the 4G WWAN card or 5G WWAN card, as applicable.
9. Install the battery.
10. Install the base cover.
11. Install the SIM card.
12. Follow the procedure in After working inside your computer.
Keyboard
Removing the keyboard
CAUTION: The information in this section is intended for authorized service technicians only.
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the SIM card.
3. Remove the base cover.
4. Remove the battery.
94
Removing and installing Field Replaceable Units (FRUs)
