Dell P127F002 User Manual

Steps
1. Align the notch on the memory module with the tab on the memory-module slot.
2. Slide the memory module firmly into the slot at an angle and press the memory module down until it clicks into place.
NOTE: If you do not hear the click, remove the memory module and reinstall it.
Next steps
1. Install the base cover.
2. Install the SIM card.
3. Follow the procedure in After working inside your computer.
Solid-state drive
Removing the M.2 2230 solid-state drive from Slot 1
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the SIM card.
3. Remove the base cover.
About this task
The following image(s) indicate the location of the M.2 2230 solid-state drive in Slot 1 and provides a visual representation of
the removal procedure.
58
Removing and installing Customer Replaceable Units (CRUs)

Dell P127F002 Specifications

General

Brand	Dell
Model	P127F002
Category	Laptop
Language	English
