About this task
The following images indicate the location of the display cable and provide a visual representation of the removal procedure.
Steps
1. Peel the tape that secures the display cable to the display back cover.
2. Disconnect the display cable from the camera module.
3. Peel the display cable to release it from adhesive and lift the display cable off the display back cover.
Installing the display cable
CAUTION: The information in this section is intended for authorized service technicians only.
Prerequisites
If you are replacing a component, remove the existing component before performing the installation process.
About this task
The following images indicate the location of the display cable and provide a visual representation of the installation procedure.
Removing and installing Field Replaceable Units (FRUs)
117
