2. Align the notch on the WLAN card with the tab on the WLAN-card slot. .
3. Adhere the WLAN card at an angle into the WLAN-card slot
4. Align the screw hole on the WLAN-card bracket with the screw hole on the WLAN card and palm-rest and keyboard
assembly.
5. Place the screw (M2x3) that secures the WLAN-card bracket to the WLAN card and the palm-rest and keyboard assembly.
Next steps
1. Install the base cover.
2. Follow the procedure in After working inside your computer.
Wireless Wide Area Network (WWAN) card
Removing the 4G WWAN card (Optional)
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the base cover.
About this task
NOTE: The following steps are for computers with WWAN support.
The following image(s) indicate the location of the 4G WWAN card and provides a visual representation of the removal
procedure.
Removing and installing Customer Replaceable Units (CRUs)
51
