Memory
Removing the memory module
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Enter Service Mode.
3. Remove the microSD card.
4. Remove the SIM card.
5. Remove the base cover.
About this task
NOTE: Latitude 5421 supports two memory slots.
The following images indicate the location of the memory module and provide a visual representation of the removal procedure.
Steps
1. Pry the retention clips securing the memory module until the memory module pops-up.
2. Remove the memory module from the memory-module slot.
NOTE: Repeat step 1 to step 2 to remove any other memory modules installed in your computer.
Installing the memory module
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
32
Removing and installing components
