Installing System Components 107
13
Install the cooling shroud. See "Installing the Cooling Shroud" on page 97.
14
Close the system. See "Closing the System" on page 85.
15
Start up the system, press <F2> to enter the System Setup program, and
check the
System Memory
setting on the main System Setup screen.
The system should have already changed the value to reflect the newly
installed memory.
16
If the value is incorrect, one or more of the memory modules may not be
installed properly. Repeat step 3 through step 15 of this procedure,
checking to ensure that the memory modules are firmly seated in their
sockets.
17
Run the system memory test in the system diagnostics. See "Running the
Embedded System Diagnostics" on page 182.
Removing Memory Modules
WARNING: The memory modules are hot to touch for some time after the system
has been powered down. Allow time for the memory modules to cool before
handling them. Handle the memory modules by the card edges and avoid touching
the components on the memory module.
CAUTION: Many repairs may only be done by a certified service technician. You
should only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized by Dell is not covered
by your warranty. Read and follow the safety instructions that came with the
product.
CAUTION: To ensure proper system cooling, memory-module blanks must be
installed in any memory socket that is not occupied. Remove memory-module
blanks only if you intend to install memory modules in those sockets.
1
Turn off the system, including any attached peripherals, and disconnect
the system from the electrical outlet.
2
If installed, remove the front bezel. See "Removing the Front Bezel" on
page 83.
3
Open the system. See "Opening the System" on page 84.
CAUTION: Handle each memory module only on either card edge, making sure
not to touch the middle of the memory module.
book.book Page 107 Thursday, February 18, 2010 2:06 PM
