96 Installing System Components
3
Slide the new power supply into the chassis until the power supply is fully
seated and the release latch snaps into place. See Figure 3-8.
NOTE: If you unlatched the cable management arm in step 1 of the previous
procedure, relatch it. For information about the cable management arm, see
the system’s rack documentation.
4
Connect the power cable to the power supply and plug the cable into a
power outlet.
CAUTION: When connecting the power cable, secure the cable with the Velcro
strap.
NOTE: When installing, hot-swapping, or hot-adding a new power supply in a
system, allow several seconds for the system to recognize the power supply and
determine its status. The power-supply status indicator turns green to signify that
the power supply is functioning properly.
Removing the Power Supply Blank
If you are installing a power supply, remove the power supply blank by pulling
outward on the blank.
CAUTION: To ensure proper system cooling, the power supply blank must be
installed in power supply bay PS2 in a non-redundant configuration. Remove the
power supply blank only if you are installing a second power supply.
Installing the Power Supply Blank
To install the power supply blank, align the blank with the power supply bay
and insert the blank into the chassis until it clicks into place.
Cooling Shroud
The cooling shroud covers the memory modules and provides air flow to the
system.
Removing the Cooling Shroud
CAUTION: Many repairs may only be done by a certified service technician. You
should only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
book.book Page 96 Thursday, February 18, 2010 2:06 PM
