Dell PowerEdge R810 User Manual

Using the System Setup Program and UEFI Boot Manager 69
Power Management Screen
Option Description
Power Management Options are OS Control, Active Power Controller,
Custom, or Maximum Performance. For all but the
Custom setting, the BIOS pre-configures the power
settings on this screen as follows:
• OS Control sets the CPU power to OS DBPM , the fan
power to
Minimum Power , and the memory power to
Maximum Performance . In this setting, all processor
performance information is passed from the system
BIOS to the operating system for control. The operating
system sets the processor performance based on
processor utilization.
•
Active Power Controller sets the CPU power to System
DBPM
, the fan power to Minimum Power , and the
memory power to
Maximum Performance . The BIOS
sets the processor performance based on processor
utilization.
•
Maximum Performance sets all fields to Maximum
Performance
.
If you select Custom, you can configure each option
independently.
CPU Power and
Performance
Management
Options are OS DBPM, System DBPM, Maximum
Performance, or Minimum Power.
Fan Power and
Performance
Management
Options are Maximum Performance or Minimum Power.
Memory Power and
Performance
Management
Options are Maximum Performance, a specified
frequency, or Minimum Power.
book.book Page 69 Thursday, February 18, 2010 2:06 PM

Dell PowerEdge R810 Specifications

General

Form Factor	2U rack server
Chipset	Intel 7500 chipset
Memory Slots	32 DIMM slots
Processor	Up to four Intel Xeon 6500/7500 series processors
Memory	Up to 512GB (32 DIMM slots): 1GB/2GB/4GB/8GB/16GB DDR3
Storage	Up to six 2.5" SAS or SATA drives
RAID Controller	PERC H700, PERC H800
Network	Four embedded Broadcom NetXtreme II 5709c Gigabit Ethernet NICs
Power Supply	Redundant 1100W or 750W AC power supplies
Expansion Slots	6 x PCIe Gen2 slots (3 x x8, 3 x x16)
Operating System Support	Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi
