Dell PowerEdge R810 User Manual

Installing System Components 89
Installing a Hard-Drive Carrier
CAUTION: Use only hard drives that have been tested and approved for use with
the SAS/SATA backplane.
CAUTION: When installing a hard drive, ensure that the adjacent drives are fully
installed. Inserting a hard-drive carrier and attempting to lock its handle next to a
partially installed carrier can damage the partially installed carrier's shield spring
and make it unusable.
CAUTION: Ensure that your operating system supports hot-swap drive
installation. See the documentation supplied with your operating system.
CAUTION: Combining SATA and SAS hard drives in the same system
configuration is not supported.
1 If installed, remove the front bezel . See "Removing the Front Bezel" on
page 83.
2 If a drive blank is present in the bay, remove it. See "Removing a Hard-
Drive Blank" on page 86.
3 Press the button on the front of the hard-drive carrier and open the handle.
4 Insert the hard-drive carrier into the drive bay until the carrier contacts the
backplane.
5 Close the hard-drive carrier handle to lock the drive in place.
book.book Page 89 Thursday, February 18, 2010 2:06 PM

Dell PowerEdge R810 Specifications

General

Form Factor	2U rack server
Chipset	Intel 7500 chipset
Memory Slots	32 DIMM slots
Processor	Up to four Intel Xeon 6500/7500 series processors
Memory	Up to 512GB (32 DIMM slots): 1GB/2GB/4GB/8GB/16GB DDR3
Storage	Up to six 2.5" SAS or SATA drives
RAID Controller	PERC H700, PERC H800
Network	Four embedded Broadcom NetXtreme II 5709c Gigabit Ethernet NICs
Power Supply	Redundant 1100W or 750W AC power supplies
Expansion Slots	6 x PCIe Gen2 slots (3 x x8, 3 x x16)
Operating System Support	Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi
