Dell PowerEdge R810 User Manual

Installing System Components 129
NOTE: The slot is keyed to ensure correct insertion of the card.
3 Press inward on the card to lock it into the slot.
Removing a VFlash Media Card
To remove the VFlash media, push inward on the card to release it, and pull
the card from the card slot.
RAID Battery
The information in this section applies only to systems with the optional
PERC controller cards without an integral battery backup unit.
Removing a RAID Battery
1 Turn off the system, including any attached peripherals, and disconnect
the system from the electrical outlet.
2 Open the system. See "Opening the System" on page 84.
3 If required, free the power/data cables from the chassis walls.
4 Press the tab on the RAID battery cable connector and pull the cable
connector out of the connector on the storage card. See Figure 3-21.
5 Pull the battery carrier release tab, and lift the battery carrier out of the
battery carrier slots on the chassis. See Figure 3-21.
6 Pull back gently on the two tabs holding the RAID battery and lift the
RAID battery from the battery carrier. See Figure 3-21.
book.book Page 129 Thursday, February 18, 2010 2:06 PM

Dell PowerEdge R810 Specifications

General

Form Factor	2U rack server
Chipset	Intel 7500 chipset
Memory Slots	32 DIMM slots
Processor	Up to four Intel Xeon 6500/7500 series processors
Memory	Up to 512GB (32 DIMM slots): 1GB/2GB/4GB/8GB/16GB DDR3
Storage	Up to six 2.5" SAS or SATA drives
RAID Controller	PERC H700, PERC H800
Network	Four embedded Broadcom NetXtreme II 5709c Gigabit Ethernet NICs
Power Supply	Redundant 1100W or 750W AC power supplies
Expansion Slots	6 x PCIe Gen2 slots (3 x x8, 3 x x16)
Operating System Support	Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi
