128 Installing System Components
Installing the Integrated Storage Controller Card
CAUTION: Many repairs may only be done by a certified service technician. You
should only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized by Dell is not covered
by your warranty. Read and follow the safety instructions that came with the
product.
1
Turn off the system, including any attached peripherals, and disconnect
the system from the electrical outlet.
2
Open the system. See "Opening the System" on page 84.
3
Hold the card by its edges and angle it between the alignment guides on
riser 1 until it is fully seated.
4
Connect the SAS data cable to the SAS data cable connector on the
integrated storage controller card. See Figure 3-20.
NOTE: Ensure that you connect the cable according to the connector labels
on the cable. The cable does not function properly if reversed.
5
Route the SAS data cable through the channel on the inner side of the
chassis.
6
Attach the cable labeled "SAS A" to connector SAS A on the backplane,
and attach the cable labeled "SAS B" to connector SAS B on the backplane.
See Figure 3-20.
7
Close the system. See "Closing the System" on page 85.
8
Reconnect the system to its electrical outlet and turn the system on,
including any attached peripherals.
VFlash Media (Optional)
The VFlash media card is a Secure Digital (SD) card that plugs into the
optional iDRAC6 Enterprise card at the back corner of the system.
Installing a VFlash Media Card
1
Locate the VFlash media slot at the back corner of the system.
2
With the label side facing up, insert the contact-pin end of the SD card
into the card slot on the module.
book.book Page 128 Thursday, February 18, 2010 2:06 PM
