112 Installing System Components
5
Reconnect the system to its electrical outlet and turn the system on,
including any attached peripherals.
Internal USB Memory Key
An optional USB memory key installed inside your system can be used as a
boot device, security key, or mass storage device. The USB connector must be
enabled by the Internal USB Port option in the Integrated Devices screen of
the System Setup program.
To boot from the USB memory key, configure the USB memory key with a
boot image and then specify the USB memory key in the boot sequence in the
System Setup program.
CAUTION: Many repairs may only be done by a certified service technician. You
should only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized by Dell is not covered
by your warranty. Read and follow the safety instructions that came with the
product.
1
Turn off the system, including any attached peripherals, and disconnect
the system from the electrical outlet.
2
Open the system. See "Opening the System" on page 84.
3
Locate the USB connector on the control panel board. See Figure 3-30.
4
Insert the USB memory key into the USB connector. See Figure 3-14.
5
Close the system. See "Closing the System" on page 85.
6
Reconnect the system to its electrical outlet and turn the system on,
including any attached peripherals.
7
Enter the System Setup program and verify that the USB key has been
detected by the system. See "Using the System Setup Program and UEFI
Boot Manager" on page 59.
book.book Page 112 Thursday, February 18, 2010 2:06 PM
