Planning: MD3600i Series Storage Array Terms and Concepts 53
• Restore snapshot virtual disk data to the source virtual disk.
Virtual disk copy generates a full copy of data from the source virtual disk to
the target virtual disk in a storage array and can be performed either online or
offline.
Source Virtual Disk
When you create a virtual disk copy, a copy pair consisting of a source virtual
disk and a target virtual disk is created on the same storage array. When a
virtual disk copy is started, data from the source virtual disk is copied
completely to the target virtual disk.
Target Virtual Disk
When you start a virtual disk copy, the target virtual disk maintains a copy of
the data from the source virtual disk. You can choose whether to use an
existing virtual disk or create a new virtual disk as the target virtual disk. If
you choose an existing virtual disk as the target, all data on the target is
overwritten. A target virtual disk can be a standard virtual disk or the source
virtual disk of a failed or disabled snapshot virtual disk.
NOTE: The target virtual disk capacity must be equal to or greater than the source
virtual disk capacity.
When you begin the disk copy process, you must define the rate at which the
copy is completed. Giving the copy process top priority slightly impacts I/O
performance, while giving it lowest priority makes the copy process longer to
complete. You can modify the copy priority while the disk copy is in progress.
For more information, see the online help topics.
Virtual Disk Recovery
You can use the Edit host server-to-virtual disk mappings feature to recover
data from the backup virtual disk. This functionality enables you to unmap
the original source virtual disk from its host server, then map the backup
virtual disk to the same host server.
Ensure that you record the LUN used to provide access to the source virtual
disk. You need this information when you define a host server-to-virtual disk
mapping for the target (backup) virtual disk. Also, be sure to stop all I/O
activity to the source virtual disk before beginning the virtual disk recovery
procedure.
book.book Page 53 Tuesday, September 27, 2011 3:13 PM

Dell PowerVault MD3620i Specifications

General

Form Factor	2U
Host Interfaces	iSCSI
Maximum Raw Capacity	192 TB
Supported Drives	SAS, SATA
RAID Levels	0, 1, 5, 6, 10, 50, 60
Host Interface	iSCSI
Processor	Intel Xeon
Drive Bays	24 x 2.5-inch
Cooling	Redundant, hot-swappable fans
Controller	Dual controllers
Cache Memory	Up to 4 GB per controller
Host Ports	4 x 1GbE iSCSI
Management Interface	Web GUI, CLI
Operating Temperature	10° to 35°C (50° to 95°F)
