Delta VFD9A0MS43ANSHA User Manual

Chapter 9 Specification  MS300 (High Speed Model)
9-2
9-1 230V Series
230V series_1-phase without built-in filter
Model VFD_ _ _ _ _ _ _
ANSHA
ENSHA
7A5MS21 11AMS21
Applicable Motor Output (kW)` 1.5 2.2
Applicable Motor Output (hp) 2 3
Output
Heavy duty
Rated Output Capacity (kVA) 2.9 4.2
Rated Output Current (A) 7.5 11
Carrier Frequency (kHz) 2~15 (default 6)
Input
Rated Input Current (A) Heavy Duty 15.8 23.1
Rated Voltage / Frequency 1-phase AC 200V~240VAC (-15% ~ +10%) / 50/60Hz
Mains Input Voltage Range (VAC) 170~264
Mains Frequency Range (Hz) 47~63
Frame C1
AC Drive Weight 1.24 kg
Cooling Method Fan cooling with fan kit
EMC Filter Optional
IP Rating
VFD_ _ _ _ _ _ _ ANSHA: IP20
VFD_ _ _ _ _ _ _ ENSHA: IP40*
230V series_1-phase with built-in filter
Model VFD_ _ _ _ _ _ _ AFSHA 7A5MS21 11AMS21
Applicable Motor Output (kW) 1.5 2.2
Applicable Motor Output (hp) 2 3
Output
Heavy duty
Rated Output Capacity (kVA) 2.9 4.2
Rated Output Current (A) 7.5 11
Carrier Frequency (kHz) 2~15 (default 6)
Input
Rated Input Current (A) Heavy Duty 15.8 23.1
Rated Voltage / Frequency 1-phase AC 200V~240VAC (-15% ~ +10%) / 50/60Hz
Mains Input Voltage Range (VAC) 170~264
Mains Frequency Range (Hz) 47~63
Frame C2
AC Drive Weight (kg) 1.8kg
Cooling Method Fan cooling with fan kit
EMC Filter Built-in
IP Rating IP20
NOTE
 IP40*: The IP rating of wiring area (main circuit terminals and control terminals, frame B/C/D/E/F) and the vent near capacitor (frame C/D/E/F)
is IP20.
 The value of the carrier frequency is a factory setting. To increase the carrier frequency, the current needs to be decreased. See derating
curve diagram of Pr. 06-55 for more information.
 When a load is a shock or impact load, use a higher level model.

Delta VFD9A0MS43ANSHA Specifications

General

Brand	Delta
Model	VFD9A0MS43ANSHA
Category	Controller
Language	English
