Chapter 9 Specification  MS300 (High Speed Model)
9-4
9-2 460V Series
460V series_3-phase without built-in filter
Model VFD_ _ _ _ _ _ _
ANSHA
ENSHA
4A2MS43 5A5MS43 9A0MS43
Applicable Motor Output (kW) 1.5 2.2 3.7
Applicable Motor Output (hp) 2 3 5
Output
Heavy duty
Rated Output Capacity (kVA) 3.2 4.2 6.9
Rated Output Current (A) 4.2 5.5 9
Carrier Frequency (kHz) 2~15 (default 6)
Input
Rated Input Current (A) Heavy Duty 5.8 6.1 9.9
Rated Voltage / Frequency 3-phase AC 380V~480VAC (-15% ~ +10%) / 50/60Hz
Mains Input Voltage Range (VAC) 342~528
Mains Frequency Range (Hz) 47~63
Frame B1 C1
AC Drive Weight (kg) 1.05 1.24
Cooling Method Fan cooling with fan kit
EMC Filter Optional
IP Rating
VFD_ _ _ _ _ _ _ ANSHA : IP20
VFD_ _ _ _ _ _ _ ENSHA : IP40*
460V series_3-phase with built-in filter
Model VFD_ _ _ _ _ _ _ AFSHA 4A2MS43 5A5MS43 9A0MS43
Applicable Motor Output (kW) 1.5 2.2 3.7
Applicable Motor Output (hp) 2 3 5
Output
Heavy duty
Rated Output Capacity (kVA) 3.2 4.2 6.9
Rated Output Current (A) 4.2 5.5 9
Carrier Frequency (kHz) 2~15 (default 6)
Input
Rated Input Current (A) Heavy Duty 5.8 6.1 9.9
Rated Voltage / Frequency 3-phase AC 380V~480VAC (-15% ~ +10%) / 50/60Hz
Mains Input Voltage Range (VAC) 342~528
Mains Frequency Range (Hz) 47~63
Frame B3 C2
AC Drive Weight (kg) 1.32 1.80
Cooling Method Fan cooling with fan kit
EMC Filter Built-in
IP Rating IP20
NOTE
 IP40*: The IP rating of wiring area (main circuit terminals and control terminals, frame B/C/D/E/F) and the vent near capacitor (frame C/D/E/F)
is IP20.
 The value of the carrier frequency is a factory setting. To increase the carrier frequency, the current needs to be decreased. See derating
curve diagram of Pr. 06-55 for more information.
 When a load is a shock or impact load, use a higher level model.
