Chapter 9 Specification MS300 (High Speed Model)
9-7
9-3 Environment for Operation, Storage and Transportation
DO NOT expose the AC Motor Drive in the bad environment, such as dust, direct sunlight, corrosive/ inflammable
gasses, humidity, liquid and vibration environment. The salt in the air must be less than 0.01 mg/cm
2
every year.
Environment
Installation
location
IEC 60364-1/ IEC 60664-1 Pollution degree 2, Indoor use only
Surrounding
Temperature
Operation
IP20/UL Open Type
-20 ~ +50 C
-20 ~ +60 C with derating
IP40/NEMA 1/UL Type 1
-20 ~ +40 C
-20 ~ +50 C with derating
Installed side by side
Storage
-40 ~ +85C
Transportation
-20 ~ +70C
No condensation, non-frozen
Relative
Humidity
Operation Max. 90%
Storage/ Transportation Max. 95%
No condense water
Air Pressure
Operation 86 ~ 106 kPa
Storage/ Transportation 70 ~ 106 kPa
Pollution Level
IEC 60721-3
Operation Class 3C2; Class 3S2
Storage Class 2C2; Class 2S2
Transportation Class 1C2; Class 1S2
Concentrate prohibited
Altitude <1000m (>1000m with derating)
Package
Drop
Storage
ISTA procedure
1A (according to weight) IEC 60068-2-31
Transportation
Vibration
Operating
IEC60068-2-6: 2Hz~13.2Hz: 1mm, peak-peak
13.2Hz~55Hz: 0.7G~2.0G
55Hz~512Hz: 2.0G
Non-operating
2.5G peak
5Hz~2kHz: 0.015" max. displacement
Impact
Operating IEC/EN60068-2-27: 15G, 11ms
Non-operating 30G
