Delta VFD9A0MS43ANSHA User Manual

Chapter 7 Optional AccessoriesMS300 (High Speed Model)
7-5
7-3 Fuse Specification Chart
 The fuse specifications lower than below table is allowed.
 For installation in the United States, branch circuit protection must be provided in
accordance with the National Electrical Code (NEC) and any applicable local codes.
To fulfill this requirement, use the UL classified fuses.
 For installation in Canada, branch circuit protection must be provided in accordance with
Canadian Electrical Code and any applicable provincial codes. To fulfill this requirement,
use the UL classified fuses.
Model Voltage/ 1-phase (3-phase)
Branch Circuit Fuses Output
(A)
VFD7A5MS21ANSXX
VFD7A5MS21ENSXX
VFD7A5MS21AFSXX
230V / 1-phase
34
Class T JJS-35
VFD11AMS21ANSXX
VFD11AMS21ENSXX
VFD11AMS21AFSXX
50
Class T JJS-50
VFD7A5MS23ANSXX
VFD7A5MS23ENSXX
230V / 3-phase
32
Class T JJS-35
VFD11AMS23ANSXX
VFD11AMS23ENSXX
50
Class T JJS-50
VFD17AMS23ANSXX
VFD17AMS23ENSXX
78
Class T JJS-80
VFD25AMS23ANSXX
VFD25AMS23ENSXX
59.4
Class T JJS-60
VFD33AMS23ANSXX
VFD33AMS23ENSXX
79.2
Class T JJS-80
VFD49AMS23ANSXX
VFD49AMS23ENSXX
112.2
Class T JJS-110
VFD65AMS23ANSXX
VFD65AMS23ENSXX
151.8
Class T JJS-150
VFD4A2MS43ANSXX
VFD4A2MS43ENSXX
VFD4A2MS43AFSXX
460V / 3-phase
18.4
Class T JJS-20
VFD5A5MS43ANSXX
VFD5A5MS43ENSXX
VFD5A5MS43AFSXX
26
Class T JJS-25
VFD9A0MS43ANSXX
VFD9A0MS43ENSXX
VFD9A0MS43AFSXX
42
Class T JJS-45
VFD13AMS43ANSXX
VFD13AMS43ENSXX
VFD13AMS43AFSXX
34.54
Class T JJS-35
VFD17AMS43ANSXX
VFD17AMS43ENSXX
VFD17AMS43AFSXX
45.1
Class T JJS-45
