Chapter 12 Description of Parameter SettingsMS300 (High Speed Model)
12-00-1
Chapter 12 Description of Parameter Settings
00 Drive Parameters This parameter can be set during operation.
Identity Code of the AC Motor Drive
Factory Setting: #.#
Settings Read Only
Display AC Motor Drive Rated Current
Factory Setting: #.#
Settings Read Only
Pr. 00-00 displays the identity code of the AC motor drive. Using the following table to check if
Pr. 00-01 setting is the rated current of the AC motor drive. Pr. 00-01 corresponds to the identity
code of Pr. 00-00.
Series 230V Series – 1-Phase
Frame C
kW 1.5 2.2
HP 2 3
Identity Code 305 306
Rated Current
for Heavy Duty
7.5 11
Series 230V Series – 3-Phase
Frame B C D E F
kW 1.5 2.2 3.7 5.5 7.5 11 15
HP 2 3 5 7.5 10 15 20
Identity Code 205 206 207 208 209 210 211
Rated Current
for Heavy Duty
7.5 11 17 25 33 49 65
Series 460V Series – 3-Phase
Frame B C D E F
kW 1.5 2.2 3.7 5.5 7.5 11 15 18.5 22
HP 2 3 5 7.5 10 15 20 25 30
Identity Code 405 406 407 408 409 410 411 412 413
Rated Current
for Heavy Duty
4.2 5.5 9 13 17 25 32 38 45
