170
[3] ZONE4 playback
The AVC-A1XVA is equipped with pre-out terminals for which the volume is adjustable as the ZONE4 output terminals.
2 ZONE4 STEREO/MONO system
• Stereo and monaural sound can be enjoyed in ZONE4. (By default, “STEREO” is selected.)
• When only one speaker is being used in ZONE4, select “MONO” for the ZONE4 channel setting at “7-1. Channel Setup” in the System
Setup Menu.
AVC-A1XVADVD player
Input
Monitor
MAIN ZONE 9.1-channel system
ZONE4 AUDIO OUT
(VARIABLE OUT)
Power amplifier
ZONE4 STEREO/MONO system
C
FL FR
SL
A
SW
SR
A
FL FR
B
SB
R
SR
B
SB
L
SL
B
Power amplifier
MULTI SOURCE AUDIO signal cable
