API operation API frames
XBee/XBee-PRO ZigBee RF Modules User Guide 133
Node Identification Indicator
Frame type: 0x95
This frame is received when a module transmits a node identification message to identify itself (when AO=0). The
data portion of this frame is similar to a network discovery response frame (see the ND command).
Frame Fields Offset Example Description
Start Delimiter
00x7E
Length
MSB 1 0x00
Number of bytes between the length and the checksum
Frame-specific
Data
LSB 2 0x20
Frame Type
30x95
64-bit Source
Address
MSB 4 0x00
64-bit address of sender
50x13
60xA2
70x00
80x40
90x52
10 0x2B
LSB 11 0xAA
16-bit Source
Network Address
MSB 12 0x7D
16-bit address of sender
LSB 13 0x84
Receive Options
14 0x02
0x01 - Packet Acknowledged
0x02 - Packet was a broadcast packet
0x20 - Packet encrypted with APS encryption
0x40 - Packet was sent from an end device (if known)
Note Option values can be combined. For example, a
0x40 and a 0x01 will show as a 0x41
Other possible values: 0x21, 0x22, 0x41, 0x42, 0x60, 0x61,
0x62
Source 16-bit
address
15 0x7D
Set to the 16-bit network address of the remote. Set to
0xFFFE if unknown
16 0x84
