API operation API frames
XBee/XBee-PRO ZigBee RF Modules User Guide 138
Route Record Indicator
Frame type: 0xA1
The route record indicator is received whenever a device sends a ZigBee route record command. This is used with
many-to-one routing to create source routes for devices in a network.
Example: suppose device E sends a route record that traverses multiple hops en route to data collector device A
as shown below.
A B C D E
If device E has the 64-bit and 16-bit addresses of 0x0013A200 40401122 and 0x3344, and if devices B, C, and D
have the following 16-bit addresses:
B = 0xAABB
C = 0xCCDD
Frame Fields Offset Example Description
Start Delimiter
00x7E
Length
MSB 1 0x00
Number of bytes between the length and the checksum
LSB 2 0x13
Frame-specific
Data
Frame Type
30xA1
64-bit Source Address
MSB 4 0x00
64-bit address of the device that initiated the route record
50x13
60xA2
70x00
80x40
90x40
10 0x11
LSB 11 0x22
Source (updater) 16-bit
Address
12 0x33
16-bit address of the device that initiated the route record
13 0x44
Receive Options
14 0x01
0x01 - Packet acknowledged
0x02 - Packet was a broadcast
Number of Addresses
15 0x03
The number of addresses in the source route (excluding
source and destination)
Address 1
16 0xEE
(neighbor of destination)
17 0xFF
Address 2 (closer hop
18 0xCC
Address of intermediate hop
19 0xDD
Address n (neighbor of
source)
20 0xAA
Two bytes per 16-bit address
21 0xBB
Checksum
22 0x80
0xFF - the 8 bit sum of bytes from offset 3 to this byte
