26
Document/Printing Paper Specification
Acceptable Documents
• Document thickness : 64gsm to 128gsm
• Document size : max. 271 x 382mm , min. 100 x 148mm
max.10.6x15-in, min. 4x6-in
• Stacking capacity in document tray: max 10 sheets (64gsm
)
•To make a new master from a document from which a master has already been made, remove
and then reload the document.
• Always use documents of the same size.
• If you load documents of different lengths, the printer may not operate correctly.
The following types of document cannot be used:
• Documents with large file-binding holes, tears, or missing parts
• Documents with staples or paper clips attached
• Documents with markedly curling ends/sides, or marked folds
• Carbon-backed documents
• Sticky documents
• Highly transparent documents such as OHP film
Acceptable Printing Paper
DP-M300 DP-M310 DP-M320
Paper thickness
Paper stacking capacity
Paper size
Printing area 204mm X 288mm 210mm X 347mm 250mm X 355mm
The following types of paper cannot be used.
• Paper with large file-binding holes
• Paper with staples or paper clips attached
• Paper with markedly curling ends/sides, or marked folds
• Carbon-backed paper
• Paper with smaller pieces of glued paper
45 gsm to 210 gsm
Feed tray : 1300 sheets (64gsm top-grade paper)
Print tray : When a cabinet is used:1300 sheets (64gsm top-grade paper)
When the printer is used on a table: 900 sheets (64gsm top-grade paper)
Max. 297mm X 364mm Max. 297mm X 364mm Max. 297mm X 420mm
Min. 100mm X 148 mm Min. 100mm X 148mm Min. 100mm X 148 mm
DP-M300 DP-M310 DP-M320
IMPORTANT
IMPORTANT
