Printing Using Basic Functions
Adjusting Paper Feed Pressure
Adjust the paper feed pressure if an feeding error occurs when using thick or thin paper
.
■
When no thick paper is fed
Adjust the paper feed pressure adjuster lev
er to “HIGH”.
■
When two pieces of thin paper are fed
Adjust the paper feed pressure adjuster le
ver to “LO
W”.
