34
Loading Documents
Positioning the Document
The document can be loaded in the “portrait” or “landscape” position.
•B5-size documents can be loaded in the “portrait” or “landscape” position.
•
Use the landscape position when enlarging or reducing from standard-size documents to
standard-size paper
, such as
A5 to
A4.
•B4 and A4 documents can only be loaded in the landscape position.
Portrait (V
ertical) Placement
Landscape (Lateral) Placement
IMPORT
ANT
35
