Supported Monitor Display Resolutions
239
The table here lists the compatible refresh rate and resolution for each
compatible video display format.
Component Signals (Analog RGB)
Signal Refresh rate (Hz) Resolution (dots)
VGA 60/72/75/85 640 × 480
SVGA 60/72/75/85 800 × 600
XGA 60/70/75/85 1024 × 768
WXGA 60 1280 × 768
60 1366 × 768
60/75/85 1280 × 800
WXGA+ 60/75/85 1440 × 900
WXGA++ 60 1600 × 900
SXGA 70/75/85 1152 × 864
60/75/85 1280 × 960
60/75/85 1280 × 1024
SXGA+ 60/75 1400 × 1050
WSXGA+ * 60 1680 × 1050
UXGA 60 1600 × 1200
* WSXGA+ is available only for EB-695Wi/EB-685Wi/EB-680Wi/EB-
675Wi/EB-685W/EB-675W and compatible only when Wide is selected as the
Resolution setting in the projector's Signal menu.
Even when signals other than those mentioned above are input, it is likely that
the image can be projected. However, not all functions may be supported.
Component Video
Signal Refresh rate (Hz) Resolution (dots)
SDTV (480i/480p) 60 720 × 480
SDTV (576i/576p) 50 720 × 576
Signal Refresh rate (Hz) Resolution (dots)
HDTV (720p) 50/60 1280 × 720
HDTV (1080i) 50/60 1920 × 1080
Composite Video
Signal Refresh rate (Hz) Resolution (dots)
TV (NTSC) 60 720 × 480
TV (SECAM) 50 720 × 576
TV (PAL) 50/60 720 × 576
HDMI Input Signal
Signal Refresh rate (Hz) Resolution (dots)
VGA 60 640 × 480
SVGA 60 800 × 600
XGA 60 1024 × 768
WXGA 60 1280 × 800
60 1366 × 768
WXGA+ 60 1440 × 900
WXGA++ 60 1600 × 900
UXGA 60 1600 × 1200
WSXGA+ * 60 1680 × 1050
SXGA 60 1280 × 960
60 1280 × 1024
SXGA+ 60 1400 × 1050
SDTV (480i/480p) 60 720 × 480
SDTV (576i/576p) 50 720 × 576
HDTV (720p) 50/60 1280 × 720
HDTV (1080i) 50/60 1920 × 1080
