Epson LS20-B Series User Manual

Maintenance 6. Joint #2
104 L
S20-B Rev.4
6.2 Replacing Joint #2 Reduction Gear Unit
A reduction gear unit consists of the following three parts. When replacing the reduction
gear unit, be sure to always replace the following parts all together as one set.
Waveform generator, Flexspline, Circular spline
For details of the three parts, refer to Maintenance: 14. Maintenance parts list.
Name
Qty.
Note
Maintenance
parts
Reduction Gear Unit 1 1798349
Tools
Hexagonal
wrench
width across flats: 2.5 mm
1
For M5 set screw
width across flats: 3 mm
1
For M4 screw
width across flats: 4 mm
1
For M5 screw
Cross-point screwdriver (#2)
For M4 screw
Torque wrench
1
Nippers
1
For cutting wire tie
Spatula
1
For apply grease
Wiping cloth
1
For wiping grease (Motor Flange)
1
For wiping grease (Bolt)
Material
Wire tie
-
Grease
Grease (SK-1A)
-
A brake is mounted on the motor of Joints #3 and #4 to prevent the shaft from moving down
and rotating due to the weight of the end effector while the power to the Controller is OFF
or while the motor is in OFF status (MOTOR OFF).
Move the shaft down to its lower limit before the replacement procedure following the
removal steps.

NOTE
