Maintenance 3. Covers
LS20-B Rev.4 73
3.5 Connector Sub Plate
CAUTION
■
Do not remove the connector sub plate
forcibly. Removing the connector sub
plate
forcibly may result in damage to the cables, disconnection, and/or contact
failure. Damaged cables, disconnection, or contact failure is extremely
hazardous and may result in electric shock and/or improper function of the robot
system.
■
When
mounting the connector sub plate, be careful not to allow the cables to
interfere with the plate mounting and d
o not bend these cables forcibly to push
them into the cover.
Unnecessary strain on cables may result in damage to the cables, disconnection,
and
/or contact failure. Damaged cables, disconnection, or contact failure is
extremely hazardous and may result in electric shock and/or improper
function of
the robot system.
When
routing the cables, observe the cable locations after removing the connector
sub plate
. Be sure to place the cables back to their original locations.
Unscrew the Connector Sub Plate
mounting bolts and remove the
plate.
Refer to
Setup&Operation 3.6
Connecting the Cables.
Connector
Sub Plate
4-M3×10
Finger Screws
(No need to unscrew)
