9-1
Chapter 9 LIST OF PERIPHERAL EQUIPMENT AND OPTIONS
The table below lists the main peripheral equipment and options that are connected to the FRENIC-Lift. Use them
in accordance with your system requirements.
Name of
peripheral
equipment
Function and application
Main peripheral equipment
Molded case
circuit breaker
(MCCB)
Earth leakage
circuit breaker
(ELCB)
*
*
with overcurrent
protection
MCCBs are designed to protect the power circuits between the power control board and
inverter’s main terminals (L1/R, L2/S and L3/T) from overload or short-circuit which in turn
prevents secondary disasters caused by the inverter malfunctioning.
RCDs/ELCBs function in the same way as MCCBs. Use the MCCBs and RCDs/ELCBs that
satisfy the recommended rated current listed below.
Input
power source
Nominal applied
motor
(kW)
Inverter type
Rated current of
MCCB and ELCB (A)
w/ DCR w/o DCR
Three-phase
200 V
5.5 FRN5.5LM1S-2
30 50
7.5 FRN7.5LM1S-2
40 75
11 FRN11LM1S-2
50 100
15 FRN15LM1S-2
75 125
18.5 FRN18.5LM1S-2
100
150
22 FRN22LM1S-2
175
Three-phase
400 V
3.7 FRN4.0LM1S-4
10 20
5.5 FRN5.5LM1S-4
15 30
7.5 FRN7.5LM1S-4
20 40
11 FRN11LM1S-4
30 50
15 FRN15LM1S-4
40
60
18.5 FRN18.5LM1S-4
75
22 FRN22LM1S-4
50 100
30 FRN30LM1S-4
75
125
37 FRN37LM1S-4
100
45 FRN45LM1S-4
150
Single-phase
200 V
2.2 FRN2.2LM1S-7
20 30
Note: A box () in the above table replaces C (China), E (EU), A (Asia) or J (Japan)
depending on the shipping destination.
Select the MCCB or RCD/ELCB with appropriate breaking capacity according to the power
supply capacity.
When connecting the inverter to the power supply, add a recommended molded case
circuit breaker and earth leakage circuit breaker* in the path of power supply. Do not use
the devices with the rated current out of the recommenced range.
*With overcurrent protection
Fire could occur.
