Chapter 8 SPECIFICATIONS
8.1 Standard Models
8.1.1 Three-phase 200 V class series
Item Specifications
Type FRN___LM1S-2_
*10
5.5 7.5 11 15 18.5 22
Nominal applied motor
*1
[kW] 5.5 7.5 11 15 18.5 22
Output ratings
Rated capacity
*2
[kVA] 10.2 14 18 24 28 34
Rated voltage
*3
[V] Three-phase 200V-240V,50/60Hz
Rated current
*4
[A] 27.0 37.0 49.0 63.0 74.0 90.0
Overload capacity [A]
(Permissible energizing time)
54.0
(10s)
74.0
(10s)
98.0
(10s)
126.0
(10s)
148.0
(10s)
180.0
(5s)
Rated frequency [Hz] 50, 60Hz
Input ratings
Normal operation
Main power supply
Phases,Voltage,Frequency
Three-phase, 200 to 240V, 50/60Hz
Auxiliary control power input
*12
Phases,Voltage,Frequency
Single-phase, 200 to 240V, 50/60Hz
Voltage/frequency variations
*8
Voltage: +10 to -15% (Voltage unbalance: 2% or less
*5
),
Frequency: +5 to -5%
Rated current
*6
[A]
with DCR 21.1 28.8 42.2 57.6 71.0 84.4
without DCR 31.5 42.7 60.7 80.1 97.0 112
Required power supply capacity
*7
[kVA]
7.4 10 15 20 25 30
Battery
operation
Main power supply
DC 24V or more in the direct current voltage conversion.
Auxiliary
control
power
input
*12
Phases, Voltage,
Frequency
Single-phase, 200 to 240V, 50/60Hz
Voltage/frequency
variations
Voltage: +10 to -15%, Frequency: +5 to -5%
Operation time
*13
[s] 180
Braking
Braking time
*14
[s] 60
Braking duty-cycle (%ED)
*14
[%] 50
Rated regenerative power
*14
[kW] 4.4 6.0 8.8 12 14.8 17.6
Minimum resistance which can be connected
[Ω]
*9
15 10 7.5 6 4 3.5
DC Reactor (DCR) Option
Applicable safety standard
EN61800-5-1:2003, EN954-1 Category3
*15
Enclosure (IEC60529) IP20
Cooling method Fan cooling
Weight/Mass [kg] 5.7 5.9 7.4 11.0 11.3 11.8
*1) Fuji’s 4-pole standard motor
*2) Rated capacity is calculated by regarding the output rated voltage as 220V for three-phase 200V series.
*3) Output voltage cannot exceed the power supply voltage.
*4) It is a value in the condition of the career frequency 10kHz and the ambient temperature 45°C. Select the inverter capacity such that the square average
current in cycle operation is 80% or less of the rated current of an inverter.
*5) Voltage unbalance [%]
=
(Max. voltage [V] - Min. voltage [V])/ Three-phase average voltage [V] x 67 (IEC61800-3)
*6) The power supply capacity is 500kVA (ten times the inverter capacity when the inverter capacity exceeds 50kVA), and the calculation value when
connecting with the power supply of %X=5%.
*7) Obtained when a DC Reactor is used.
*8) An acceptable variation of the main power supply and the control power supply assistance input.
*9) The admissible error of minimum resistance is ±5%.
*10) Type List
A box (
) in the above table replaces C, E, A or J depending on the shipping destination.
A box (
) in the above table replaces A for the inverter without a CAN port
*12) The same AC power as the main power supply input is connected for the backup of the control circuit power source.
*13) It is a value in the condition of the career frequency 10kHz and the ambient temperature 45°C. Use the inverter such that the square average current in
battery operation is 80% or less of the rated current of an inverter.
*14) Braking time and duty cycle (%ED) are defined by cycle operation at the rated regenerative power as shown in the figure below.
0
Cyclic period :T
0
Time [s]
Braking time : T
1
Reated regenerative power
％ED = ×100
T
1
T
0
Regenerative power [kW]
Braking time : T
1
*15) The inverter that last 2 digits of a software version are from 50 to 99 corresponds to this standard.
