Control Panel
27
Product Overview
2
Control Panel
The following describes the names and functions of components on the control panel.
123
456
789
0
＃
C
スタート
ジョブ確認
設定確認
（未登録）
メニュー
コピー
機械確認
(メーター 確 認 )
認証
データ
エラー
クリア
ポーズ
短縮
ストップ
リセット
節電
主電源
割り込み
2
3
4
5
6
7
8
9
10
11121317
21
20
19
18
14
15
16
1
No. Component Function
1 Touch screen Displays messages required for operation, and buttons for various features.
You can directly touch the touch screen to instruct operations and set
features.
2 <Log In/Out> button Lights up when a user is authenticated in the System Administration mode,
the Authentication mode, or the Accounting mode. Displays the User ID
entry screen for entering the System Administration mode, the
Authentication mode, or the Accounting mode. Press this button to exit
these modes.
3 <Job Status> button Press this button to check or cancel the current job, to check or print stored
jobs, or to check completed jobs.
4 <Machine Status> button Press this button to check the machine status and meters, to check the
status of consumables, and to print reports.
5
<Powe
r
Saver>
button
When the
machin
e is not
used for
a while, i
t enters
the Power
Saver mod
e to
reduce power consumption. When the Power Saver mode is active, the
<Power Saver> button lights up.
Press this button to enter or exit the Power Saver mode.
6 <Clear All> button Returns the settings you made to the default values. The machine returns to
the same state as when it is powered on.
7 <Interrupt> button Press this button to suspend a copy or print job in progress to have the
machine process another job. During the Interrupt mode, the <Interrupt>
button lights up. Pressing the <Interrupt> button again exits the Interrupt
mode and resumes the suspended job.
8 <Stop> button Press this button to pause the current job or communications.
To Next Page
