14 Problem Solving
490
Problem Solving
14
8
Insert the Tray 2 into the machine, and push
until it stops.
Important • Do not use excessive force on the tray. Doing
so could damage the tray or the inside of the
machine.
9
Close the rear cover.
Paper Jams in Fusing Unit
The following describes how to clear paper jams occurring in the fusing unit.
Important • Ensure nothing touches or scratches the surface (black-colored film) of the belt unit. Scratches, dirt,
or oil from your hands on the film of the belt unit may reduce print quality.
• Protect the drums of the drum cartridges against bright light. If the rear cover remains open for
more than 3 minutes, print quality may deteriorate.
1
Open the Tray 5 (bypass) and remove the
remaining paper on the tray.
2
Grasp both sides of the Tray 5 (bypass), and
then pull the tray from the machine.
3
Pull out the Tray 1 halfway from the machine
until it stops.
To Next Page
