Activity Report
595
Appendix
15
Activity Report
You can print activity reports to check whether a transmission is successfully completed or
not. In the report, a remote terminal name and a result or a status of each operation are
recorded by outgoing and incoming transmission.
Note • The use of ApeosWare Log Management (sold separately) or ApeosWare Accounting Service (sold
separately) allows you to import the contents of an Activity Report to a computer. For information
on ApeosWare Log Management and ApeosWare Accounting Service, refer to the manuals provided
with the software.
For information on how to print the activity report, refer to "Print Reports" (P.72).
Item Description
No. The serial numbers for transmissions is shown.
Doc. Job numbers that the machine automatically assigned to
documents when the documents were received.
Remote Station Information on recipient to which transmission is made is recorded
in the following order of priority.
îš„
Transmitting (speed dialing)
1. Recipient
2. Remote terminal name
3. G3 ID (including spaces)
4. Tel. No.
5. Communication mode EC (or G3, SG3)
îš„
Transmitting (when all digits are dialed)
1. Remote terminal name
2. G3 ID (including spaces)
3. Tel. No.
4. Communication mode EC (or G3, SG3)
îš„
Receiving
1. Remote terminal name
2. G3 ID (including spaces)
3. Communication mode EC (or G3, SG3)
Note • You can set the number of character digits displayed for the
recipient whether the first 40 digits or the last 40 digits. For
details on setting up, see "Activity Report - Recipient" (P.124).
The factory default displays the first 40 digits.
Start Time The date and time that the communication began are shown.
In Batch Send, the start time of the transmission for each
document is recorded.
Duration The duration of the transmission is displayed. In Batch Send, it is
the length of time taken to transmit each document is recorded.
To Next Page
