Working w ith the notebook
Ports on the Port Replicator
PortReplic ato rPorts
11
1
2
3
4
6
7
8
9
12
10
5
1 = Security Lock device
2 = U S B 3.0 ports
3 = ESata port
4 = LAN port
5 = DisplayPorts
6 = D V I-D monitor port
7 = VGA monitor port
8 = DC input connector (DC IN )
9 = Headphones and microphone port
10 = ON/OFF switch
11 = Connect o r on the Port Replicator for
the docking port on the und erside
of the noteboo k
12 = Unlocking lever
The DVI port and DisplayPort cannot be used at the same time .
Multi Moni toring
Up to three displays are supported: with the optional Port Replicator you can take multi-tasking to
the next level. With the ability of running three monitors you will have enoug h r eal-estate to cut
from one document and paste to another and keep track of email without closind one app so you
can see another. This is the key to beingt efficient in today’s bu siness environments.
Po
ssible monitor combinations:
LIFEBOOK ports Port Replicator ports
L
CD notebook
m
onitor
D
isplayPort
D
isplayPort
D
VI-D port
V
GA port
-
XX
--
-
X
-
X
-
Fujitsu 45
