Working w ith the notebook
Connecting the AC adapter to the Port Replicator
3
1
2
► Connect the power cable to the
AC adapter (1).
► Plug the pow er cable into the power
outlet (2).
► Connect the AC adapter cable to the DC
jack (DC IN) o f the P ort Replicator (3).
Power Outlets will vary from country to country, see chapter "When
travel ling in other countries ", Page 16.
When the notebook is connected to a Port Replicator, the operating system creates
a hardware profile for the "Docked" mode. In this profile, for example, the setting is
saved as to which monitor was last used for output. This profile will be loaded, as
soon as the notebook is connected to a Port Replicator of the same type.
Switching on the notebook via the port replicator
► Press the ON/OFF switch on the port
replicator to switch the notebook on.
The power-on indicator of the P ort
Replicator lights up.
Fujitsu 47
