Fujitsu ScanSnap S1300 User Manual

ScanSnap Manager Icon and Operations (for Mac OS users)
171
■ Profile Menu
This menu appears when you click the ScanSnap Manager icon .
Currently saved profiles are displayed in a list.
You can switch to the previously saved scan settings by selecting a profile from the Profile
menu.
If you are not using the Quick Menu, you can select a profile from the Profile menu.
For details about how to save and manage profiles, refer to "Saving Scan Settings" (page
183).
z Clear the [Use Quick Menu] checkbox in the ScanSnap setup window to display the Profile
menu. The Profile menu does not appear when this checkbox is selected.
z You can also display the Profile menu by selecting [Profile] from ScanSnap Manager menu.
z If the current ScanSnap Manager overwrote its previous version when it was installed,
profiles saved in the previous version of ScanSnap Manager are carried over.
Click
Profile menu example

Fujitsu ScanSnap S1300 Specifications

General

Film scanning	No
Color scanning	Yes
Maximum scan size	216 x 360 mm
Scanner type	Sheet-fed scanner
Sensor type	CIS
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	10 sheets
USB version	2.0
Standard interfaces	USB 2.0
Scan media weight	64 - 104.7 g/m²
Dimensions (WxDxH)	284 x 99 x 77 mm
Power requirements	AC 100 - 240V, 50/ 60 Hz
Non-operating relative humidity (non-condensing)	20 - 80 %
Minimum RAM	512 MB
Minimum storage drive space	2197 MB
Sustainability certificates	ENERGY STAR
Power consumption (standby)	5 W
Power consumption (typical)	9 W
Operating temperature (T-T)	5 - 35 °C
Certification	RoHS

Weight and Dimensions

Depth	99 mm
Width	284 mm
Height	77 mm
Weight	1400 g
